PRODUCT OVERVIEW
The Dual STROBESWITCH™ with Beacon is a compact, cost-effective dual detector system designed to provide fast, reliable access control for emergency responders. This system detects an emitter signal from emergency response vehicles, automatically opening access gates and simultaneously providing a high-visibility signal for bystanders and emergency response personnel.
Ideal for HOA communities, gated businesses, municipal yards, airports, and warehouses, this system ensures that emergency vehicles equipped with strobe emitters can quickly and safely access restricted areas without delays.
How the Dual STROBESWITCH™ with Beacon Works
- Emergency vehicles use a specialized emitter to send an optical signal, which can be strobe, LED, or Infrared/IR.
- The TOMAR 2795-2 STROBESWITCH™ detects the emitter signal and verifies the format.
- Once verified, the system activates a relay which can control automatic gates, garage doors, and other security mechanisms.
- The MicroLED® beacon provides a visual warning signal, increasing awareness and safety, in either red or amber (selectable during installation).
- Designed for indoor and outdoor operation, the Dual STROBESWITCH™ with beacon functions reliably in bright sunlight, adverse weather conditions, and low-visibility environments.
Who this Helps
- Fire Departments & First Responders: This system ensures rapid, automatic gate access and visually notifies first responders and nearby personnel by providing a visual signal informing them that the gate is about to open.
- Homeowners & Business Owners: Knowing their gate is equipped with TOMAR’s STROBESWITCH™ system provides peace of mind, ensuring that emergency personnel can quickly and efficiently access the property when needed most.
- Gate Installers: With a streamlined design, this system reduces installation time and overall costs, making it a more efficient and affordable alternative to similar gate access solutions.
Key Features & Benefits
STROBESWITCH™ Access Control System
- Fast Emergency Access: Designed to instantly open gates upon detecting a valid strobe signal.
- Reliable & Interference-Free: Immune to radio frequency interference (RFI) and rejects false signals from flashlights, vehicle lights, and flashing signs.
- Wide Compatibility: Works with TOMAR and *GTT OPTICOM® optical signal emitters, ensuring seamless integration with emergency response systems.
*GTT and Opticom are trademarks of Miovision Technologies Incorporated - Versatile Installation: Designed for indoor or outdoor use, handling harsh weather and extreme conditions.
- Customizable Activation Settings: Offers 0-30 minute delay options and a continuous latch mode for flexible access control.
2795-BCN-AR Dual Strobeswitch™ with Beacon Specifications
- Range: 200 feet typical, but depends on the intensity of the strobe emitter
- Field of View: 10º vertical, 90º horizontal
- Signal Acquisition Time: 0.64 seconds
-
Frequency:
- F14: 14.035 Hz ± 0.25 Hz (high priority)
- F10: 10.000 Hz ± 0.25 Hz (low priority)
-
1790M–2 Power Module:
- Voltage: 12–24VDC AC/DC
- DPDT relay output: 2A @ 30VDC, 0.6A @ 120VAC
- Time Delay: 0–30 minutes plus continuous latch mode
- Remote reset
MicroLED® Warning Beacon
- High-Output Optical Technology: Increases visibility and safety with a wide-angle light spread.
- Dual-Color LED Selection: Users can switch between Amber or Red (default: Red).
- Neobe® Flashing Technology: Provides a distinct, attention-grabbing signal.
- Weatherproof & Corrosion-Resistant: Manufactured to NEMA 4X standards for water, dust, and corrosion resistance.
- Durable Construction: Features a spun-welded lens for maximum impact resistance.
- Universal Voltage Compatibility: Operates on 12-80 VDC, making it compatible with a wide range of power systems.
MircoLED® Specifications
- NEMA Rating: NEMA 4X
- UL Standard: UL583
-
Flash Rates:
- Red Flashing: 75 Septuplets FPM
- Amber Flashing: 107 Quadruplets FPM
- Operating Voltage: 12-80 VDC
- Operating Temperature: -40-65 °C
Potential Applications - Perfect for High-Security & Emergency Access Locations
- Gated HOA Communities
- Apartment Complexes
- Maintenance Yards & Warehouses
- Airport Security Gates
- Municipal Storage & Public Works Yards
- Secure Industrial & Commercial Facilities
Why Choose the Dual STROBESWITCH™ with Beacon?
- Trusted by emergency responders nationwide for seamless gate access.
- Superior optical signal processing ensures precise activation without false triggers.
- Designed for all environments, from bright sunlight to harsh weather.
- Long-lasting & durable with industry-leading ingress protection.
- Compatible with TOMAR & *GTT OPTICOM® emitters, allowing flexible integration
*GTT and Opticom are trademarks of Miovision Technologies Incorporated
Helpful Links
FAQ's
Does this system detect IR or Infrared Emitters?
Yes, our Strobeswitch detectors will detect all brands of IR, Infrared, LED & Strobe optical emitters.
Can the time a gate is open be adjusted?
Yes, there is a dial on the power module so that you can adjust the time a gate remains open from 0-30 minutes.
Does this product have a warranty?
Yes, all Strobeswitch products are backed by a 2-year warranty
Does the system provide notification when an optical emitter is detected?
Yes, there is a small red confirmation light inside of the 1790-1014 detector eye.
Do you offer a system that will work at gates using solar?
Yes, our SSLC detectors require a very low draw which makes them ideal for solar applications.
Does the 2795-2 dual detector system include the power module?
Yes, the 1790M-2 power module is included inside of the provided enclosure.
Do you offer a device that can test the system after installation or for periodic testing?
Yes, the 1760-14 handheld tester.
TOMAR's Envelope of Safety® Explained
Since 1969, TOMAR has had one primary focus – to provideequipment that can be relied on in an emergency to help save people and property. To focus on that mission while being a value-adder to our community and those we serve worldwide, TOMAR developed the Envelope of Safety®.
